NEWMEN rim 27.5″ Evolution SL A.35 aluminum | 28 holes
This high-end aluminum rim was developed for riders who want to embark on all-mountain adventures with light but stable wheels. Like all Newmen Evolution SL components, the rim consists of a high-strength aluminum alloy and impresses with first-class mechanical properties and low weight.
35mm inner width is an optimal combination between width and weight and allows lower tire pressure, which is reflected in better grip and more comfort. The flared and reinforced rim flanges are more resistant to damage from punctures and give the tire a rounder shape and thus even better cornering.
The rim profile with the straight nipple contact surface is specially designed for the use of specially developed washers (MG washer) and ensures very high “spoke pull out” values with very low wall thickness in this area.Technical specifications:
Area of intended use : All Mountain, light Enduro
Material: aluminum
Rim Type: Clincher (clincher and folding)
Brake type: only for disc brake
ETRTO: 584×35
EARTH: n/a
Inner width: 35 mm
Outer width: n/a
Rim Height: 22.5mm
Offset: no
Number of holes: 28 holes
tubeless capable: yes
ASTM classification: n/a
recommended tire width: 63-71 mm
maximum tire pressure: 2.3 bar.
Maximum system weight: 125 kg (rider, bike, clothing and possibly luggage)
maximum spoke tension: 1200N
Features: MG Washer
Finish: Anodized
Colour: black with white and gray decals
Weight according to the manufacturer: 525g
Weight weighed: 561gScope of delivery: 1x NEWMEN rim 27.5″ Evolution SL A.35 aluminum | 28 holes, without MG washer
A notice:
The special washers (MG washers) required to build a wheel must be ordered separately and are not included in the scope of delivery!
EAN:
4054571183385
MPN:
90576
